| Model | Process pipe diameter range (mm) | Screw diameter (mm) | L/D | Main power (KW) | Output (Kg/h) |
|---|---|---|---|---|---|
| SXG-30 | 1.0 - 6.0 | 30 | 28-30 | 5.5 | 5-10 |
| SXG-45 | 2.5 - 8.0 | 45 | 28-30 | 15 | 25-30 |
| SXG-50 | 3.5 - 12.0 | 50 | 28-30 | 18.5 | 32-40 |
| SXG-65 | 5.0 - 16.0 | 65 | 28-30 | 30/37 | 60-75 |
| SXG-75 | 6.0 - 20.0 | 75 | 28-30 | 37/45 | 80-100 |
| OD (mm) | Producing speed (m/min) | Diameter control accuracy (≤mm) |
|---|---|---|
| ≤ 4.0 | 65-120 | ±0.04 |
| ≤ 6.0 | 45-80 | ±0.05 |
| ≤ 8.0 | 30-48 | ±0.05 |
| ≤ 10.0 | 23-32 | ±0.08 |
| ≤ 12.0 | 18-26 | ±0.10 |
| ≤ 16.0 | 10-18 | ±0.10 |
| Cutting length | ≤ 50mm | ≤ 400mm | ≤ 1000mm | ≤ 2000mm |
|---|---|---|---|---|
| Cutting accuracy | ±0.5mm | ±1.5mm | ±2.5mm | ±4.0mm |
The process pipe diameter range depends on the model selected. It spans from a minimum of 1.0 mm (with the SXG-30 model) up to a maximum of 20.0 mm (with the SXG-75 model).
For pipes with an outer diameter (OD) of ≤ 4.0 mm, you can achieve producing speeds ranging from 65 to 120 meters per minute.
The systems offer high-precision control. The diameter control accuracy is maintained within ±0.04 mm for OD ≤ 4.0 mm, and does not exceed ±0.10 mm even for larger outer diameters up to 16.0 mm.
Main power requirements start at 5.5 KW for the entry-level SXG-30 and scale up to 37/45 KW for the high-capacity SXG-75 model.
For short cutting lengths of ≤ 50mm, the machine achieves a tight cutting accuracy tolerance of ±0.5mm. For longer sections up to 2000mm, the accuracy tolerance is within ±4.0mm.
The maximum output is achieved by the SXG-75 model, which offers a production capacity of 80 to 100 Kg/h.
